Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power

Name: Automatic Hydraulic Injection Molding Machine 1165KW Heater Power
Brand: HAIJIA
Price: 1 USD

Buy cheap Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power product

Brand Name : HAIJIA

Model Number : HJF 240

Certification : CE ISO9001

Place of Origin : China (Mainland)

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000set/sets per year

Delivery Time : 20-30days

Packaging Details : Standard Export Package for Injection Machine

Max.Pump Pressure : 16

Pump Motor Power : 18.5

Heater Power : 11.65

Machine Dimension : 5.4*1.5*2

Machine Weight : 7

Oil Tank Capacity : 340

Contact Now

SPECIFICATION		HJF240
Screw Type		A	B	C
Screw Diameter	Mm	50	55	60
Screw L/D Ration	L/D	22.2	20	18.2
Shot Size(Theoretical)	cm3	508	593	706
Injection Weight(PS)	g	462	534	642
Injection Rate	g/s	148	179	202
Injection Pressure	MPa	180	160.8	128
Screw Speed	rpm	0~180
Clamping Force	KN	2400
Opening stroke	Mm	490
Space Between Tie Bars	mm	530*510
Max.Mold Height	mm	530
Min.Mold Height	mm	200
Ejector Stroke	mm	165
Ejector Tonnage	KN	70
Max.Pump Pressure	MPa	16
Pump Motor Power	KW	18.5
Heater power	KW	11.65
Machine Dimension(LWH)	M	5.41.52
Machine weight	T	7
Oil Tank Capacity	L	340

Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power

Characteristic

The machine use the high-performance servo dynamic control system, the oil pump as the power source, having the characteristics as follow: high response,saving energy, low noise, high-control precision, and have the breakthrough in the prefect connection of the electrical servo and hydraulic drive system.

High Energy saving

Under the ideal working state, Power consumption is 40% less than that of variable displacement pump and 70% less than that of fixed displacement pump, save the cost effectively.

High precision

Precise control of low pressure & low flow, repeating precision is less than 0.5%. Weight error of the products is 0.4%~0.7%, with semi-close loop system nearly.

Low noise

Different from ordinary fixed pump injection molding machine, servo power-saving injection molding machine is working only when necessary. And working noise is less than 70dB, will be much quieter for your working area.

Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power
